| Elo Interactive Digital Signage (IDS) | |||||||||
| Outlook | Model | Screen Size |
Technology | Touch points |
Resolution | Operating System |
Configurations | Peripherals | Support Download |
| I-Series for Windows (15.6" and 21.5") | |||||||||
 |
15i2 | 15.6" | PCAP
Zero Bezel |
10 | 1920x1080 | No OS | Intel
Celeron 1.6 GHz (up to 2.24 GHz) N3160 Quad-Core Processor 2GB DDR3L SODIMM on 1 of 2 slot (Expandable to 8GB) 128GB 2.5" 7mm SATA SSD Front-facing HD webcam Two 2W internal speakers Wi-Fi 802.11 a/b/g/n/ac 1 x LAN RJ45 (Gigabit) |
MSR
(E001002) NFC/RFID Reader Barcode Reader 2D Barcode Scanner (*Coming soon) Tabletop Stand
 Pole Stand  |
Data Sheet |
| Drawing | |||||||||
| Windows 7 | |||||||||
| Windows 10 | |||||||||
 |
15i5 | 15.6" | PCAP Zero Bezel |
10 | 1920x1080 | No OS | Intel i5 2.3GHz
(up to 3.3 GHz) 6500TE Quad-Core Processor 4GB DDR4 SODIMM on 1 of 2 slot (Expandable to 16GB) 128GB 2.5" 7mm SATA SSD Front-facing HD webcam Two 2W internal speakers Wi-Fi 802.11 a/b/g/n/ac 1 x LAN RJ45 (Gigabit) |
Data Sheet |
|
| Drawing | |||||||||
| Windows 7 | |||||||||
| Windows 10 | |||||||||
 |
22i2 | 21.5" | PCAP
Zero Bezel |
10 | 1920x1080 | No OS | Intel Celeron 1.6
GHz (up to 2.24 GHz) N3160 Quad-Core Processor 2GB DDR3L SODIMM on 1 of 2 slot (Expandable to 8GB) 128GB 2.5" 7mm SATA SSD Front-facing HD webcam Two 2W internal speakers Wi-Fi 802.11 a/b/g/n/ac 1 x LAN RJ45 (Gigabit) |
MSR (E001002) NFC/RFID Reader Barcode Reader 2D Barcode Scanner (*Coming soon) Tabletop Stand
Pole Stand |
Data Sheet |
| Drawing | |||||||||
| Windows 7 | |||||||||
| Windows 10 | |||||||||
 |
22i5 | 21.5" | PCAP
Zero Bezel |
10 | 1920x1080 | No OS | Intel
i5 2.3GHz (up to 3.3 GHz) 6500TE Quad-Core Processor 4GB DDR4 SODIMM on 1 of 2 slot (Expandable to 16GB) 128GB 2.5" 7mm SATA SSD Front-facing HD webcam Two 2W internal speakers Wi-Fi 802.11 a/b/g/n/ac 1 x LAN RJ45 (Gigabit) |
Data Sheet |
|
| Drawing | |||||||||
| Windows 7 | |||||||||
| Windows 10 | |||||||||
| I-Series for Android (10.1", 15.6" and 21.5") | |||||||||
 |
10i1 | 10.1" | PCAP
Zero Bezel |
4 | 1280x800 | Android 4.4.2 | ARM-A15-quad-core-1.7GHz 16GB-EMMCFlash 2GB-DDR3 Front-facing HD webcam Two 2W internal speakers WiFi 802.11 b/g/n 1x RJ45 |
MSR
(E001002) NFC/RFID Reader Barcode Reader 2D Barcode Scanner (*Coming soon) Pole Stand |
Data Sheet |
| Drawing | |||||||||
 |
15i1 | 15.6" | PCAP Zero Bezel |
10 | 1920x1080 | Android 4.4.2 | ARM-A15-quad-core-1.7GHz 16GB-EMMCFlash 2GB-DDR3 Front-facing HD webcam Two 2W internal speakers WiFi 802.11 b/g/n 1x RJ45 |
Data Sheet |
|
| Drawing | |||||||||
 |
22i1 | 21.5" | PCAP Zero Bezel |
10 | 1920x1080 | Android 4.4.2 | ARM-A15-quad-core-1.7GHz 16GB-EMMCFlash 2GB-DDR3 Front-facing HD webcam Two 2W internal speakers WiFi 802.11 b/g/n 1x RJ45 |
Data Sheet |
|
| Drawing | |||||||||
| Large Format Touchscreen Signage | |||||||||
 |
3202L | 31.5" | Infrared with Bezel |
10 | 1920x1080 | N/A | Elo Windows Module (No OS/Win7/Win8.1/Win10) Elo Android 4.4.2 Module (*Available separately, please contact our sales representative.) |
MSR (E001002) NFC/RFID Reader Barcode Reader 2D Barcode Scanner (*Coming soon) Webcam |
Data Sheet Drawing |
| PCAP Zero Bezel |
|||||||||
| Non-Touch | N/A | ||||||||
 |
4202L | 42" | Infrared with Bezel |
10 | 1920x1080 | N/A | Data Sheet Drawing |
||
| PCAP Zero Bezel |
|||||||||
| Non-Touch | N/A | ||||||||
 |
4602L | 46" | Infrared with Bezel |
10 | 1920x1080 | N/A | Data Sheet Drawing |
||
| PCAP Zero Bezel |
|||||||||
| Non-Touch | N/A | ||||||||
 |
5501LT | 54.6" | Infrared
with Bezel |
10 | 1920x1080 | N/A | Elo
Windows Module (No OS/Win7/Win8.1/Win10) (*Available separately, please contact our sales representative.) |
NFC/RFID
Reader WebCam |
Data Sheet |
| Drawing | |||||||||
 |
5551L | 54.6" | Infrared
with Bezel |
10 | 3820x2160 (4K) |
N/A | Elo
Windows Module (No OS/Win7/Win8.1/Win10) (*Available separately, please contact our sales representative.) |
NFC/RFID
Reader WebCam |
Data Sheet |
| Drawing | |||||||||
 |
7001LT | 69.5" | Infrared
with Bezel |
20 | 1920x1080 | N/A | Elo
Windows Module (No OS/Win7/Win8.1/Win10) Elo Android 4.4.2 Module (*Available separately, please contact our sales representative.) |
MSR
(E545781) NFC/RFID Reader WebCam |
Data Sheet |
| Drawing | |||||||||
